Name: 3nh SC-10 Portable Colorimeter for Color Quality Control Testing Equipment
Brand: Guangdong Threenh Technology Co., Ltd.
Availability: InStock

Home Products Colorimeter

3nh SC-10 Portable Colorimeter for Color Quality Control Testing Equipment

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	3nh

Contact Now

Detailed Product Description

Industry Test Instrument:	Color Measurement Equipment	Warranty:	1 Year
Customized Support:	OEM, ODM	Type:	Testing Machine
Application:	Plastic Testing, Textile Testing, Paper Testing, Leather Testing, Wood Testing, Laboratory Testing, Lab Testing	Protection Class:	Ip55
Power:	Li-ion Battery 3.7V 3200mAh	Accuracy:	0.01
Voltage:	Other

Color Space

CIE LAB L(Lightness): 0 is black,100 is white a(Red-Green): positive values are red; negative values are green and 0 is neutral b(Blue-Yellow): positive values are yellow,negative values are blue abd 0 is neutral CIE LCH L: Lightness,value is the same in each scale C: Chroma H:Hue Angle dE Total Color difference Delta-E is a measurement used to indicate how much a color deviates from an accepted standards.The higher the dE, the more inaccurate the color.

Delta E	Meaning
0~1	A normally invisible difference
1~2	very small difference, only obvious to a trained eye
2~3.5	Medium difference, also obvious to an untrained eye
3.5~5	An obvious difference
>6	A very obvious difference

Products Description

CR6 Portable Colorimeter
ColorReader CR6 (Industrial Enhanced Version) is the creative work of 3nh's core technical elites and joint well-known designers. It embodies the technical strength completed in a short time, the professionalism of high-intensity testing, and the traditional bloodline of innovation and excellence.
Color Reader CR6 (Industrial Enhanced Version) is an innovative tool for color measurement, reading, color card retrieval and color difference evaluation. It integrates powerful color recognition capabilities in a safe and portable body, and seamlessly connects with mobile phone devices through Bluetooth, which makes the traditional color measuring instrument glow with different application charm.

Application

Single measurement aperture for accurate color difference control in plastic and electronic, paint and ink, textile and garment printing and dyeing, printing, ceramics and other industries.

Model	SC-10
Battery	rechargeable lithium-ion battery 3. 7V@ 3200mAh
Color Space	CIE LAB
Dimension	2056780mm
Display Data	Colorimetric Value, Color Difference Value Storage
Errors between each instrument	ΔE*ab 0.4
Illuminating/Viewing Geometry	8°/d
Lamp Life	5 years, more than 1.6 million measurements
llluminant	D65
lnterface	USB
Measuring Aperture	4mm
Measuring Time	1.5s
Observer	CIE 10°
Operating Temperature	0-40°C(32-104°F)
Optional accessory	miniature thermal printer, powder test box
Repeatability	ΔE* ab ≤0. 03（Average of 30 measurements of standard white plate）
Screen	TFT 2.8 inch(16: 9)
Sensor	silicon photodiode
Standard	CIE No.15, GB/T 3978
Storage	100 Standards, 10000 Samples
Storage temperature	-20-50°C(-4-122°F)
temperature	Graph, PASS/FAIL Result, Color Offset
Weight	400g

Product packaging

Company Profile

Shenzhen 3nh/Threenh Technology Co., Ltd. is a high-tech enterprise. We research, develop, produce and market photoelectric detection products in color management field and color management field. After years of intensive research, 3nh has launched NH series colorimeter, NR series colorimeter, NS series spectrophotometer, ISO12233 resolution test chart, optical image test solution and specific standard illuminant. Our products are widely used in plastic, electronic, paint, ink, textile, garment, printing anddyeing, food, medical, cosmetic, optical image test industries and the field of scientific research, school and laboratory. Our products are exported all around the world. We can provide customization service which has been well received by customers.

3nh adheres to the business philosophy of "people-oriented, customer first, technological innovation, sustainable development" to meet customers' demands continuously, to create value for customers and to achieve a win-win situation and common development.

Certifications

Guangdong Threenh Technology Co.,Ltd.passed CE, ISO 9001, ROHS, FCC, TUV certifications.

Exhibition

We join all over the world exhibitions, including China plas, China coating, Printing and Packaging, and CIOE etc.

FAQ

Frequently Asked Questions
1. Which brands are 3nh models to equal?
Answer: 3nh color test instruments compared with KONICA MINOLTA and X-rite and BYK.
2. Are you a trader or a manufacturer?
Answer: We 3nh is a manufacturer, we research and develop, design and produce, market and sell color measuring instruments and gloss meters. We offer OEM&ODM service for free.
3. What's your main market.
Answer: We sell to the global market.
4. How long is your delivery time?
Answer: Generally it is 1-3 working days after the payment confirmed.
5. What is your payment terms?
Answer: The payment term is 100% T/T in advance.
6. What's your minimum order quantity (MOQ)?
Answer: Our MOQ is 1 set. If you order more than 3 sets, we can provide discount.
